1100 kw AC Electric Motor
1500 hp, 6-pole, 3300v, 400 frame, TOSHIBA < Back
| Type | AC Electric Motor |
| Make | Toshiba |
| Model Number | TIKK FCKNW AS1359 |
| Manufacture origin | Japan |
| KW | 1100 |
| HP | 1500 |
| Poles | 6 |
| Rated RPM | 988 |
| Rated Frequency | 50 hz |
| Rated Voltage | 3300 v |
| F/L Amps | 240 A |
| Protection Rating | IP 55 |
| Mount | B3 Foot |
| Frame | 400-1250 |
| Weight | 4530 kg |
| Total Length | 2400 mm (incl. shaft) |
| Total width | 1950 mm (incl. terminal boxes) |
| Total height | 1320 mm |
| Centre shaft height | 400 mm |
| Feet Measurements | Across 'A' - 800mm (approx), Front to Back 'B' - 1250 mm |
| Front hole to end of shaft | 'C' - 280 mm (approx) |
| Shaft diameter | 130 mm |
| Shaft length | 240 mm |
| Insulation Class | F |
| Quantity | 1 |
| Condition | Full reconditioned critical spare, warehouse storage |
