1600 kw AC Electric Motor

2200 hp, 4 pole, 3300 volt, 450 frame < Back
TypeAC Electric Motor
MakeSiemens
Model Number1RN4 456-4HV20-Z
Year Of Manufacture2009
KW1600
HP2200
Poles4
Rated RPM1490
Rated Frequency50
Rated Voltage3300
F/L Amps330
Protection RatingIP 55
MountB3 Foot
Frame450
Weight5,050 kg
Total Length2200 mm (incl. shaft)
Total width1755 mm (incl. RHS Box from D.E)
Total height1600 mm
Centre shaft height450 mm
Feet Measurements1400 mm front to back, 850 mm Across
Shaft diameter140 mm
Shaft length200 mm
NotesOnly 150 hrs run time
Quantity2
ConditionUsed VGC. Electrically OK
