212 kw DC Electric Motor
285 hp, 3000 rpm, 500 volt, 200 frame, Baumuller < Back
Type | DC Electric Motor |
Make | Baumuller |
Model Number | GNA 200 MNA |
Manufacture origin | Germany |
KW | 212 |
HP | 285 |
Rated RPM | 3000 |
Rated Voltage | 500 v |
F/L Amps | 451 A |
Protection Rating | IP23 |
Mount | B3 Foot |
Frame | 200 |
Total Length | 1190 mm (incl. shaft & tacho) |
Total width | 610 mm (incl. box) |
Total height | 440 mm |
Centre shaft height | 200 mm |
Feet Measurements | Across 'A' - (approx) 315 mm, Front to Back 'B' - 540 mm |
Shaft diameter | 70 mm |
Shaft length | 140 mm |
Quantity | 1 |
Condition | Unused. Decommissioned critical spare. excellent condition, warehouse storage |
